SOLAR ATTIC Space Heating System
The SOLAR ATTIC Space Heating System is an Integrated Solar Package which features innovative design for the ultimate in comfort and convenience for both domestic hot water heating and space heating systems.
Unlike other solar heating systems on the market today, our system combines sophistication, reliability, low cost and maximum performance without affecting the aesthetic qualities of residential or commercial design.
Gone are odd-shaped rooflines, vast expanses of South windows and obtrusive solar equipment. The only evidence of a Solar "AlR" Collector Design is the flush-mounted glazing on a portion of the South-facing roof which resembles a large skylight.
The Solar "AlR" Collector system was developed through extensive research and is sized to provide 100% heating for both the space and water in the commercial or residential environment. Users gain valuable independence from ever-escalating fuel costs and a sense of pride that arises from conserving our natural resources without giving up space heating comforts.
HEATING
SIMPLE AUTOMATIC CONTROLS
SIMPLE AUTOMATIC CONTROLS
The Space Duct Heating System is a forced-air type that operates very much like a conventional forced-air duct system.
A portion of the south facing roof is used as a solar "AIR' collector by attaching a specially selected glazing material to rafters instead of wood sheathing and shingles.
SIMPLE AUTOMATIC CONTROLS
SIMPLE AUTOMATIC CONTROLS
SIMPLE AUTOMATIC CONTROLS
Designed to automatically control the collection, storage, and distribution of solar "AIR" heat by means of sensors in the collector and living area. By continually monitoring these sensors, the controller selects the optimum mode of operation and maintains the desired temperature.
Back-up heat systems are selected only when the collector and storage heat are depleted. The back-up heating may be any available source of heat including electrical, gas, oil, etc... and incorporated In the air handler for distribution when the Solar "AIR" is depleted from the storage
COLLECTOR GLAZING
SIMPLE AUTOMATIC CONTROLS
COLLECTOR GLAZING
The Solar "AIR" Collector Glazing is designed for the surface area needed for the heated space and attached directly to the rafters replacing the sheathing and conventional roofing.
The glazing is a double layer of greenhouse fiberglass reinforced clear panel (FRP) which allows the appropriate amount of radiation (SUNLIGHT) to enter the Solar "AIR" Collector and converts the short wave radiation into long wave heat to be used directly into the space to be heated or stored for later use.
THERMAL STORAGE
WHAT DOES IT COST?
COLLECTOR GLAZING
Thermal storage is a designed space and is located within the structure.
Washed #4 railroad ballast are used & contained within an insulated space such as a cubical ( 6’ x 6’ x 7" ) in a basement layout.
SYSTEM COMPONENTS
WHAT DOES IT COST?
WHAT DOES IT COST?
The Solar "AIR" Collector "AIR" Handler for any type of back-up heating source includes individual motorized dampers, a back-up electric duct heater and instructions on interfacing the house coil of air conditioner or heat pump backup.
Mounting can be vertical or horizontal and located in the basement, closet, or storage area. Collectors are pre-assembled, ready for installation and include a one-year warranty. Maintenance consists of changing filters periodically and oiling the motor once a year.
WHAT DOES IT COST?
WHAT DOES IT COST?
WHAT DOES IT COST?
The Solar Attic heating System has been designed as an integral part of the building structure from construction phase to completion.
As one of the least expensive systems solar heating systems available, additional cost is estimated at $15,000 for a 1500 square foot building.
